Ozone destructor works on a catalytic principle where MNo2 is used as a catalyst. The purpose of ozone destruction is to convert ambient ozone gas into harmless oxygen before releasing it into the atmosphere. The residual un-dissolved ozone from the hydraulic system is segregated using an ozone vent. The outlet of the vent is connected to the ozone destruct through an expander where water is isolated and drained out and the gases are passed to the destruct.

Working Principle

Un-dissolved gaseous ozone from the application is connected at the bottom of the ozone destructor, where any moisture in the ozone gas is evaporated using the heater. Once the moisture in the gas is evaporated, dry ozone passes ahead & reacts with manganese dioxide & gets converted into oxygen & released into the atmosphere. Insert figure of formula/ equation

2 O3 + 3 MnO2 3 MnO2 + 3 O2

Advantages

• The efficiency of ozone to oxygen is > 99%.
• The conversion of ozone into oxygen is very fast.
• Most preferred & economical technique in destroying un-dissolved ozone

Scope of application

• Ozone Water treatment tank, Suitable for 2000 - 5000-liter tank.
• ozone remaining in disinfected cabinet/rooms
• ozone remaining after environmental disinfection etc.
